Transforming Complex Engineering Into a $400M Judgement

When the North Texas Tollway Authority faced the catastrophic failure of a retaining wall system, the outcome of the case depended on helping the jury understand highly technical engineering concepts.

That’s where Fox-AE’s 3D animations became invaluable. Let’s take a look at the NTTA’s strategic use of graphics.

Picture of Steve Malouf, Malouf & Nockels

Steve Malouf, Malouf & Nockels

"Fox-AE is the most sophisticated presentation company in the country. First-rate in every respect. Use Fox-AE whenever possible - your client and the jury will thank you. Your opposing counsel will not."

The Case Explained

The NTTA paid a company to design 96 mechanically stabilized earth walls (MSE) that lined 6.5 miles of highway. These walls were supposed to have a minimum safety factor rating of 1.5 and a guarantee to last 100 years. The project was completed in 2012, but in 2020 one of the walls failed exposing a systematic design deficiency.

Animations Come to Life

Due to pressure from the soil surrounding the structure, the reinforced fill was slowly pushed out from the soil, causing the integrity of the wall to fail. Using Fox-AE’s sophisticated 3D models, the NTTA was able to show that the angle of the structure was not stable enough to sustain the pressure from the soil.

A Critical Angle

The NTTA used our animation models to demonstrate a critical flaw in the angle of the MSE. The structure was compromised due to the soil surrounding the retaining fill pressing at an unstable 24 degree angle. Graphic one depicts the distribution of force on a 24 degree angle in contrast with a more stable 38 degree angle.

The Answer is in the Numbers

The NTTA used our models to show that had the wall been built using a more stable angle, the result may have been different. Graphic two is an example of another 3D model depicting how using a 38 degree angle in the walls construction would have achieved a sufficient safety rating and ensured the integrity of the wall.

$400,000,000 Judgment

The court ruled in favor of the NTTA, and their legal team was able to secure a judgment of $400,000,000. In this highly technical case, the use of 3D animations and models were critical to communication with the jury.
